Description
Key Features
1. Integrated Compute, Storage, and Networking
Each server node contributes CPU, memory, storage, and networking resources to the HCI cluster, allowing for easy scaling and balanced workloads across nodes.
2. High Availability and Redundancy
-
Node Failover: In case of a hardware failure, the system automatically redistributes the virtual machines (VMs) to other nodes within the cluster, ensuring zero downtime.
-
Data Replication: Storage is replicated across multiple nodes, ensuring that no single point of failure affects the overall infrastructure.
3. Scalable Architecture
-
Easily scale from a small deployment to a large multi-node cluster by adding additional servers (nodes) without disrupting ongoing operations.
-
Cluster Expansion: Each new node increases both compute power and storage capacity, ensuring consistent performance growth.
4. Unified Management and Automation
-
Centralized Management: A single dashboard for managing all nodes, VMs, storage, and networking, providing a unified view of the entire infrastructure.
-
Automation and Orchestration: Automated provisioning of VMs, resource allocation, and failover processes, reducing administrative overhead.
5. Networking and Security
-
Advanced Networking: Supports VLANs, network bonding, and SDN features for efficient network management and traffic isolation.
-
Enhanced Security: Integration with Active Directory and LDAP for centralized authentication. Secure communication between nodes ensures data integrity and
Datasheet-HCI
Technical Specification for each node
| Form Factor | Per Node 1U |
| Processor | Dual Intel® Xeon Platinum, Gold, Silver, Bronze scalable
processors |
| Chipset | Intel C741 |
| Memory | 32 DDR5 slots, maximum 5,600 MT/s memory speed |
| Storage | Front: 10x 2.5″ slots (SAS/SATA, NVMe SSD optional, hot- swappable). Rear: 2x 2.5″ slots (SAS/SATA, NVMe SSD
optional, hot-swappable). |
| RAID Support | RAID 0/1/5/6/10/50/60 with power-off protection |
| Node Connectivity | Fibre Channel (FC) support for high-speed SAN
connectivity |
| Networking | Dual OCP 3.0 interfaces (PCIe 5.0 x16 + x8), supports up to
6 PCIe slots |
| External Ports | 5 USB ports, 2 VGA ports, 1 Serial port |
| Power Supply | 1+1 hot-swappable redundant power supplies. Options: 550W, 800W, 1200W, 1600W, 2000W (80PLUS Platinum
or Titanium). |
| Cooling | Eight high-efficiency fans with N+1 redundancy and
intelligent cooling system |
| Operating Temperature | +5ºC to +45ºC (depends on configuration). |
| Storage Temperature | -40ºC to +65ºC |
| Humidity | 8% to 90% RH (no condensation). |
| Altitude | Operable up to 3,000m (performance degradation at
higher altitudes). |
| Dimensions | 432mm (W) x 43mm (H) x 780mm (D), excluding flanges
and rails |
| Weight | Maximum configuration: About 27kg (excluding rails) |
| Certifications |
